    IEC NMC 18650 NiCoMn Electric Bicycle Battery Pack High Energy Density

    Ask Lasest Price
    Brand Name : YM
    Model Number : YM-72T30-M1
    Certification : MSDS, UN38.3, CE, IEC, ISO9001
    Price : Negotiable
    Payment Terms : Western Union, Paypal, T/T, L/C
    Supply Ability : 10,000 units per month
    Delivery Time : 5-10 working days
    • Product Details
    • Company Profile

    IEC NMC 18650 NiCoMn Electric Bicycle Battery Pack High Energy Density


    Quick Detail:


    1. Better low temperature performance than LiFePO4: 70% rated capacity under -20℃

    2. EV level grade AAA Lithium NCM battery cells are used

    3. Reliable and precise BMS to protect the battery from over-discharge, over-charge, over-current, over-heat, etc and monitor the battery status

    4. Support high discharge rate up to 3C and 1C charge rate

    5. Smart version with bluetooth & APP is optional


    Description:

    Compact Size 72V 30AH Electric Motorcycle Lithium NMC Battery Pack Better Low Temperature​ Performance


    NCM lithium batteries’ performance advantages are in many aspects. It enjoys the advantage of high energy density. That is, under same size it has more capacity so that users can drive longer distance. Besides, MNC battery has the advantage of better low-temperature performance. If your winter there is very cold, then NMC battery is recommended to you.


    This battery pack consists of 240pcs 18650 - 2500mah cells via 20S12P. Smart BMS is built-in. It is suitable to power motor or terminal load ≤2000W.

    Communication function is optional. Communication function is via Bluetooth which enables users to monitor the battery status easily. If you want LED screen to show the battery data on the battery directly, that is workable too. We can customize for you.


    OEM ODM services are offered. Welcome to Email us or call us to discuss your unique needs!


    Specifications:

    Nominal voltage72V
    Nominal capacity30AH
    Cell typeNMC
    Cell configuration3.6V 2500mah cell via 20S12P
    Resistance≤100mΩ
    HousingCoated iron housing
    Weightapprox 16.5kg
    Dimensions270*230*155(mm)
    discharging current30A
    Discharging cut-off voltage63V
    Charging methodConstant Current - Constant Voltage
    charging current5A
    Charging voltage84V
    Cycle life800+ cycles
    Working temperature-20℃~65℃(discharging)
    0℃~45℃ (charging)
    Storage temperature-20℃~45℃

    Remarks:

    Battery connectors are optional. Please choose the connector type or give us your specified connector models!


    DC Output Connectors:


    IEC NMC 18650 NiCoMn Electric Bicycle Battery Pack High Energy Density


    AC Input Plugs:


    IEC NMC 18650 NiCoMn Electric Bicycle Battery Pack High Energy Density


    Applications:

    Electric motorcycle, electric tricycle, electric scooter, etc


    Competitive Advantages:


    1-Product advantages:

    a. The cells we use are from China top cell manufacturers or imported cells from Sumsang, Panasonic, LG, etc.

    b. BMS are realiable. BMS within 24S, we develop by ourselves. BMS above 24S, we purchase from China top 3 BMS manufacturers.

    c. Advanced battery pack assembly technologies ensures the finished battery packs are of high quality.

    d. Except pure battery packs, we also do integrated system solutions such as ev powertrain kit and energy storage system.


    2-Company advantages:

    a- Good Quality Management:
    Our Pack production base for mass order is suitable for making electric car lithium batteries. It has passed TS16949 Quality System, ISO14001 Environmental System and OHSAS18001 system certifications. And we have passed the test of the National Motor Vehicle Product Quality Supervision and Inspection Center. We always do daily production as per these systems.

    b- Advanced hardware and software facilities

    We established high-precision three-coordinate measuring machines, projectors, universal material tensile machines, and other measuring instruments to ensure the effective quality data.

    c- Technical advantage:

    Our technical team are all from China famous electric vehicle manufacturers. They all have more than 10 years' industry experiences. They have excellent R&D abilities.


    Tag:

    electric motorycle lithium battery, 72v 30ah lithium battery, NMC battery pack
